Power Driver Board Continued ...
J127-1 White-Green, 9.8Vac from xformer secondary
Jt27-2 White-Green, 9.8Vac loop from Jl12-1
J127-3 White-Green, 9.8Vac from xformer secondary
J127-4 Keys
J127-S White-Green, 9.8VAC loop from Jt12·3
J128-1 White·Red, 16Vac loop from J1 02-2
J128-2 White-Red, 16Vac from xformer secondary
J128-3 White-Red, 16Vac loop from Jt02-4
J128·4 White-Red, 16Vac from xformer secondary
J128-5
Black-Yellow, 16Vac loop from J102-6
J128-6 Black-Yellow, 16Vac from xformer secondary
J128-7 Key
J128-8 Black-Yallow, 16Vac loop from Jl02-9
J128-9 Black-Yellow, 16Vac from xformer secondary
J129·1 Red, 9Vac from xformer secondary
J 129-2 Red, 9Vac from transformer secondary
J129-3 Key
J129·4
Blue-White, t3Vac from xformer secondary
J129-S Blue-White, 13Vac loop from Jl01-4
J129-6 Blue-White, 13Vac from xformer secondary
J129-7 Blue-White, 13Vac loop from Jt01·6
Jt30-Not Used
J13t-Not Used
J132-Not Used
J 133-1 Red-Orange, +SOV to coils
J 133-2 Red·Brown, +SOV to coils
J 133-3 Red-Black, +50V to coils
J133·4 Key
J133-5
N/C
J133-6 Red-White, +20V to playfield flash lamps
J134-1
N/C
J134-2
N/C
J134-3
N/C
J13S·4 Key
J134-S Red-White, +20V to insert panel flashlamps
J135- Not Used
J 136- Not Used
J137- Not Used
J 138- Not Used
J139-
Not Used
J140-1 Key
J140-2 Gray-Yellow, +12V to playfield boards
J 140-3 Black, ground to playfield boards
J140-4
N/C
J141-1 Key
J141-2 Gray-Yellow, +12V to Coin Door Board J2-2
J 141-3 Black, ground to Coin Door Board
J2-1
J141-4
N/C
3-28
