Item Part Number
Description
1
01-9211
Plfd. Hanger Bracket Assy. (2)
2
01-11781
Leg Support (2)
3 A-20439
Shooter Lane Auto Kicker Assy.
4 A-19963-1
Ball Trough Assembly Complete
5 A-15849-R-2
Flipper Assembly, Lwr. Right
6 A-17811
Kicker Arm (Slingshot) Assy.
B-9362-R-3
Coil & Bracket Assembly
7 A-20605
9-Lamp PCB Assembly
8 A-20655
Drop Diverter Assembly
9 A-20453-1
Eject Assembly (2)
10 A-20600
5-Lamp Board Assembly
11
A-9415-2
Jet Bumper Coil Assembly
12 A-20607
14-Lamp Board Assembly
13 A-20625
2-Way Popper Assembly
14 A-20680
3-Ball Popper Assembly
15 A-17949.1-2
Plfd. Slide Mech. Assy. R.
16 A-20654
Disappearing Post Assy.
17 A-20665
Ball Gate Actuator Assy. (2)
18 A-20601
3-Lamp Board Assembly
19 A-17949.1-1
Plfd. Slide Mech. Assy. L.
20 A-17932-1
Disappearing Post Assy.
21 A-20606
4-Lamp Board Assembly
22 A-20738
Flipper Assembly, Left
23 A-20620
5-Lamp PCB Assembly
24 A-20602
4-Lamp PCB Assembly
25 A-20614
Gorilla Assembly
~
.
If'
~
1-
0 ;0
.~
26 A-17811
Kicker Arm (Slingshot) Assy.
I~.O~-
- I ~.
B-9362-L-2
Coil & Bracket Assembly
lo!'
-0 -
r--
27 A-15849-L-2
Flipper Assembly, Lwr. Left
IO~
_-
28 A-18159
10-0pto PCB Assembly
~, It:--.~
29 A-20697
6-Lamp Board Assembly
e
o
.e:::::: :.,
-0
Lower Playfield Parts
