DISAPPEARING JET - BOOM BALLOON
The game contains a Disappearing Jet Bumper that raises and lowers during game play. A coif lifts the
jet mechanism up to playfield level, where a latch holds the jet up in position. Balls from the playfield can
now hit, the bumper. Then the latch coil pulls in and the jet lowers back down to be flush with the
playfield.
adjustable cap
switches
bumper coil
B 0
I/~
lift coil
height adjus tment
latch coil assy
UP
main pin assy
lift spring
main shaft
1-58
