PLAYFIELD LOCKING SUPPORT ARM
Cirqus Voltaire comes with a left-side mounted playfield locking support arm, When you lift the playfield
fully up the metal arm automatically moves into place. Press the arm down to unlock
it
betore lowering
the playfield.
Inpor
t
o.n+l
CORRECT ALIGNMENT
Loosen to adjust ARM
TO RE-ADJUST THE ARM:
1 - Loosen both ESNA NUTS.
2 - SLIDE the bracket forward.
3 - CHECK the Playfield Alignment.
4 -
Re-tighten the ESNA NUTS. Install two SCREWS
(4808-01175-08)
to SECURE SAFETY ARM in
place.
