50062-IN
Backbox Insert Assembly
Item Part Number
Description
Item Part Number
Description
1 03~9696.1
Insert Body
30 H-22001
Cable Assembly
2 03-9698-1
Channel-Top
31 31-2952-3
Plastic
-r-
Clear
3 03-9698-2
Channel - Side
32 07-6688-19N Rivet: 118x
7/32"
Long
4
03-9697
Channel - Lift
33 4006-01003-08 Mach. Screw, #6·32 x
Yz"
5 31-2832
Backglass - Screened
34 4700-00005-00 Flat Washer:
9/64
x
7/16
x 21 gao
"6 31-2836-1
Decal
35 4406-01119-00 Nut #6-32 ESN
7 04-10916
Grille - Large
36 20-8712-25
Retaining Ring 14"Oia.
8 04-10917
Grille -Small
37 4700-00072-00 Flat Washer:
17/64
x
Yz
x 21 gao
9 8-11873
Bottom Arch Kick Assy.
38 04-10914
Shaft - Plastic Spinner
10 4008-01 003-08 Mach. Screw: #8-32 x
Yz"
39 03-7568
Flipper Bushing
*11 31-2835-2
Decal
40 31-2833-2
Plastic - Clear
12 4408-01119-01 Nut #8-32 ESN
41 RM-23-01
Shrink Tubing
13 20-10451
Ball Plastic,
1-1/4"
42 5045-12914-00 Capacitor, .10MFD, SOV, ±20%
14 31-2833-5
Plastic Clear
43 03-7655-4
Clip Harness 14"
15 31-2833-7
Plastic Clear
44 RM-21-06
#18 Vinyl Figs Sleeve
16 31-2833-8
Plastic Clear
45 4406-01128-00 Nut #6-32 KEPS
17 31-2833-4
Plastic Clear
46 5555-12924-00 Speaker - Tweeter
18 31-2833-1
Plastic Clear
47 5555-12856-00 Speaker - Mid Range
19 20-9658-1
Standoff - PCB Supt.
Y2"
48 03-9454
Cable Tie 4" Long
20 20-9658-2
Standoff - PCB Supt.
%"
49 03-7722-4
Quick Clip,
W
21 03-8044-13
Post Clear
50 5647-12693-19 Subminiature Switch
22 23-6694~1
Rubber Ring, Black
51 01-14800
Support Bracket
23 4106-01114-08
res
#6 x
Yz"
52 01-14659
Rollover Switch Bracket
24 24-8768
Bulb #555 6.3V" .2SA.
53 4002-011 05-06 Mach. Screw, #2-56 x
3/8"
25 24-8863
Socket G.!. White
54 5070-09054-00 Diode 1N4004
26 24-8802
Bulb #906 13v, 0.S9A.
55 H-21985-1.1
. Cable Assembly
~
27 24-8861
Socket - Flasher Black
*56 31-2835-2
Decal
28 4008-01113-20
Mach. Screw, #8-32 x
1-1/4"
*57 31-2835-3
Decal
29 03-9255-5
S~acer. #8, .733 Long
.• Not available for individual sale. Order decal set 31-2835
&
31-2836 respectively.
