A-21953
Ring Master Assembly
Item Part Number
Description
,
1 04-10938
Main Mounting Bracket
2 04-10940.1
Motor
&
Cam Bracket
3 14-8035
Motor
4
04-10937;1
Cam Assembly
5 01-14709
Shield Bracket
6 31-2952-1
Shield
7 4020-01196-16 Set Screw:
#1/4-20
x 1.0
8 4420-01141-00 Nut
#1/4-20
Flangrip
9 4008-01168-06 Mach. Screw: #8-32 x
3/8"
10 H-21975
Cable Assembly
11 4700-00080-00 Flat Washer:
5/16
x
3,4
x 16ga.
12 4323-01158-06 Set Screw:
#1/4-28
x
318"
13 07-6688-19N Rivet:
1/8
x
7/32"
Long
14 4700-00070-00 Flat Washer:
3/16
x
5/8
x 16ga ..
15 5070-09054-00 Diode, 1N4004
16 5647-12693-01 Switch
17 03-9822
Switch Spacer
18 4002-011 05-1 0 Mach. Screw: #2-56 x
5/8"
19 02-4576
Roller Cam
20 20-8712-37
Retaining Ring
21 H-21973
Cable Assembly
22 02-5313
Guide Lift Rod
23 20-8712-25
Retaining Ring
24 H-18601-10
Cable Assembly
25 01-14708.1
Lift Bracket
26 20-9610
Bearing - Flange
4
27 03-9821
Spacer Lift Rod
28 01-14707
Ball Cup Bracket
29 04-10939
Spring Assembly
30 4408-01119-01 Nut #8-32 ESN
31 A-15782
Motor Cir Bd w/Spacers
32 4008-01168-14 Mach. Screw: #8-32 x 7/8"
33 5792-0911 0-00 Connector
34 31-2833-13
Plastic Washer
35 01-14712
Bulb
&
Socket Bracket
36 07-6688-17N Rivet
1/8
x
5/32"
Long
37 4700-00004-00 Flat Washer:
5/32
x
3/8
x 21 gao
38 A-17802
Socket
&
906 Bulb Assembly
39 02-5312
Magnet Post
40 01-14710
Magnet Plate ( Bottom)
41 20-10197
Magnet w/Breaker
42 01-5311
Magnet Core
43 31-2947.1
Ring Master
44 03-9454
Cable Tie 4"
45 03-7655-4
14"Cable Clamp
46 4408-01128-00 Nut #8-32 KEPS
47 4008-01 003-08 Mach. Screw: #8-32 x
W'
48 01-8240
Nut Plate #2-56
49 RM-23-01
Heat Shrink 1" Long
• Not available for individual sale. Order Decal Set 31-2833.
2-28
