A-21564
Disappear Jet Bump Assembly
Item Part Number
1 04-10732
2 04-10733
3 04-10911-1
4 FL-11630/50V
5 10-517
6 02-5297
7 4700-00023-00
8 20-8712-18
9 4020-01196-16
10 4420-01117-00
11 4700-00005-00
12 AE-23-800
13 04-10731.2
14 4008-01168-08
15 4408-01119-01
16 A-21554
17 03-9674
18 4104-01042-06
19 4006-01003-10
20 A-4754
21 03-9675
22 03-6035-15
23 03-6009-A5
24 10-7.
25 23-6702
26 4406-01119~00
27 SW-1A-213
28 01-3670
29 4005-01005-16
30 H-21972.1
31 03-9454
32 03-7067-6
33 4700-00007-00
34 03-7655-4
35 10-96
36 A-6892
37
SM1-26-600
38 4008-01021-07
39 4701-00003-00
40 4700-00089-00
41 01-12348
42 4006-01003-04
43 A-15821
44 01-14677.2
45 4410-01132-01
46 01-14678
47 23-6694-1
48 02-5303
49 31-2835-9
50 04-10888
51 01-1747
52 01-5492
53 01-5493
54 02-3406-1
55 10-326
56 03-7066
57 23-6626
58
RM-23-0l
59 01-14803
Description
Jet Bumper Main Bracket
Armature Assembly
%
Coil Centering Bracket
Flipper Coil (Red)
Spring
Guide Shaft
Flat Was her:
13/64
x 5/8 x 16ga.
Retaining Ring
Set Screw:
#1/4-20
x 1.0
Hex Nut #1/4-20
Flat Washer: 9/64 x 7/16 x 21gao
Coil Assembly (Yellow)
Jet Bumper Mounting Bracket
Mach. Screw #8-32 x
W'
Hex Nut #8-32 ESN
Jet Bumper Lamp PCB Assy.
Bumper Cap - Flat
Sh. Metal Screw: #4 x
3/8"
Mach. Screw: #6-32 x 5/8"
Bumper Ring Assembly
Bumper Body - Foremost
BumperWafer (Orange)
Bumper Base (White)
Spring
Bumper Plug
Hex Nut #6-32 ESN
Jet Bumper Switch Assembly
Switch Plate
Mach. Screw: #5-40 x 1.0
Cable Assembly
Cable Tie 4" (Not Shown)
Coil Tubing
.
Flat Washer:
5/320x 7/16
x 16ga.
Harness Clip
14"
Spring
Frame & Eyelet Assembly
Coil Assembly
Mach. Screw: #8-32 x 7/16"
Lockwasher #8 Split
Flat Washer: 11/64
x
7/16
x
16ga.
Ball Gate Coil Bracket
Mach. Screw: #6-32 x
W'
Armature Sub- Assembly
Armature Latch Bracket
Nut #10-32 ESN
Jet Bumper Bracket
Rubber Ring
3/32"
(Black)
Jet Bumper Post
Decal
Jet Bump Bracket/Stop Assy.
Coil Retainer Bracket
Link Armature - Steel
Link Armature - Bakelite
Coil Plunger
Spring
Coil Tubing
Rubber Grommet
Heat Shrink
1"
Long
Support Bracket
2-26
