TABLE OF CONTENTS
Rules and Shotmaps 1 to 22
Section 1 - Game Operation & Test Information 1-1
(System WPC) ROM Summary 1-1
Pinball Game Assembly Instructions 1-2
Game Control Locations 1-6
Game Operation 1-7
Raising the Playfield 1-8
Menu System Operation and Main Menu 1-10
Bookkeeping Menu 1-11
B.1 Main Audits 1-11
B.2 Earnings Audits.......................................................................................... 1-11
B.3 Standard Audits 1-11
B.4 Feature Audits 1-12
B.5 Histograms , 1-14
B.6 Time-Stamps · 1-15
Printouts Menu 1-15
Test Menu 1-16
T.1 Switch Edges Test, ..· 1-16
T.2 Switch Levels Test. 1-16
T.3 Single Switch Test. 1-16
T.4 Solenoid Test, 1-17
T.5 Flasher Test. 1-17
T.6 G.1. Test. 1-17
T.7 Sound and Music Test, 1-18
T.8 Single Lamp Test, 1-18
T.9 All Lamps Test. 1-18
T.10 Lamp and Flasher Test.. 1-18
T.11 Display Test. 1-18 .
T.12 Flipper Coil Test.. 1-19
T.13 Ordered Lamp Test. 1-19
T.14 Lamp Row-Col 1-19
T.15 DIP Switch Test, ~ 1-19
T.16 Up/Down Jet Test ; · 1-19
T.17 DiverterTest. 1-20
T.18 Magnet Test. 1-20
T.19 Ringmaster Test 1-22
T.20 Empty Balls Test. 1-22
Utilities Menu 1-23
U.1 Clear Audits 1-23 . .
U.2 Clear Coins ; ; 1-23
U.3 Reset H.S.T.D 1-23
U.4 Set Time & Date 1-23
U.5 Custom Messages 1-23
·U.6 Set Game 1.0 1-23
Copyright 1997 Williams Electronics Games, Inc.
