#867 -- "CAMELOT"
GAME ADJUSTMENTS
PLAYFIELD PANEL POST ADJUSTMENTS:
The playfield panel has posts that can be moved at operators
discretion to increase or decrease scoring. "Liberal" and
"conservative" positions of these posts are shown on "play-
field panel layout and parts sheet".
BELL ADJUSTMENT PLUG:
Located on back box insert. This plug provides positions to
ring bell for "10 point" scores, "lOa point" scores, or both
"10 and 100 point" scores.
HI-SCORE ADJUSTMENT PLUGS:
Located on back box insert. These (2) plugs combine to provide
a wide range of score coverage at which replays can be awarded.
Recommended plug settings that correspond to score cards shipped
with game are shown on "hi-scores adjustment sheet".
BALLS PER GAME ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to operate game on "5 ball" or "3 ball" play.
MATCH FEATURE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to operate game with or without "match number feature"
replay award.
2ND
&
3RD COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to give "2 to 6 plays" per coin thru 2nd and/or 3rd
coin chutes.
1ST COIN CHUTE ADJUSTMENT PLUG:
Located on 2 coin unit. (On front cabinet mounting board.).
This plug provides positions to give "1 play per two coins"
or "1 play per coin" thru 1st coin chute.
