INSTRUCTIONS FOR ALTERING COIN CHUTES
EQUIPPED WITH A FLIP-OVER DEVICE.
FOR 1 COIN- FOR 1 PLAY
FIGURE
1
OR 2 COINS - FOR 1 PLAY
FIGURE 2
" X"
" X "
"A"
"A"
"B"
L
FLIP-OVER
LEVER
FLIP-OVER
LEVER
1
COIN - FOR
1 PLAY
(FIGURE
1):
Wire form "A" should be in position as shown in Figure 1. Flip-over lever should
rebound from wire form "A" and return to position shown in Figure 1 everytime a
coin is inserted. All coins passover the coin trip switch wire "B".
2
COINS - FOR
1 PLAY
(FIGURE
2):
Wire form "A" should be in position as shown in Figure 2 (see note). Flip-over
lever should alternate from side to side. 1st coin should go to cash box without ac-
tuating coin trip switch wire "B", 2nd coin should passthe coin trip switch wire "B"
and returns flip-over to position as shown in Figure 2.
NOTE:
To change from 1 coin play to 2 coin play or vice versa - loosen screw "X" and
move screw, bushing & wire form "A" to position as required - shown in Figure 1
position as required - shown in Figure 1 or Figure 2.
When using 1 coin for 1 play, wire form "A" should not under any circumstances
be allowed to enter the "Banana" slot and cause binding of flip-over lever.
