GAME ADJUSTMENTS
PLAYFIELD
PANEL
POST
ADJUSTMENTS:
Posts that
control left
and
right outlane opening
on panel (see
panel
sketch)
can be moved to make
access
to outlanes easier or
harder for ball to enter.
Easier entry will decrease
playing time and
scoripg.
Harder entry
will 1ncrease
playing time
and
scoring.
HI-SCORE ADJUSTMENT PLUG:
r
Located on
back
box lite
insert.
This plug provides a wide range
of coverage at which hi-score credits can be scored~ (See the
score adjustment
card
i~
back
box
for plug
positions) •
•
MATCH FEATURE ADJUSTMENT
PLUG:
Located on front cabinet
mountiLnq
board.
This
plug provides
positions to
operate match featu~e
on
or off.
HI-SCORE FEATURE ADJUSTMENT PLUG:
Located on
front cabinet mounting
board. This plug
provides
poistions to
award
Hi-Score credit
or
extra 'ball.
BALLS PER
GAME ADJUSTMENT
PLUG:
Located
on
frqnt
cabient mounting
board.
This
plug provides
positions to operate gam~ on 5 baIlor 3 ball
play.
1ST COIN CHUTE
ADJUSTMENT
PLUG:
Located on the 2 coin unit, on front cabinet mounting
boar~.
This·
plug provides
positions
to/·give 1
play for 1 coin or 1>
play
for 2 coins thru th~, 1st (nickel) coin
chrite.,
'
2ND COIN CHUTE ADJUSTMENT PLUG:
.
Located
on
front
cabinet
mount.Lnq
board.
This
plug
provides .
po~itions
t6
give 1 play
f6r
1 coin or 2 plays:for 1 coin thru the
2nd (dime)
coin
chuce., ,
NOTE: .
When this plug. is
set,
for
2' "
plays -
1· coin " b.rown-whLte (male
plug)
'wire
on'.
3rd ~oin'
'chu't,e
adjustment
must
be
.Ln
position 2. .
',
3RD CO"IN CHUTE.
ADJUSTMENT,'
PLUG:
.
.
'Loca"t:ed
on fron't cabinet
mount.Lnq
bo·ard,.' t.his pl'ug pzovadea posi.-.,
tions to'
gi.ve,'2 to
~~ ,: ,'play's
for,
1,
'coin
thru
the
3rd.
(quar:ter)'
coin
chute.
US'e
orange-whi·te,'.
(male
p
Luq) wire' 't'o set number ,
of
cr~i~ts.,
•
•
I
•
•
•••••
"
.
-8-
