#1033 BOW
&
ARROW
INSTALLATION AND GENERAL GAME OPERATION INSTRUCTIONS
INSTALLATION
On
all
games there
are
certain
items
that
should
be
checked
after shipment. These are· visual inspections
which
may
avoid
time consuming service work later. Minor troubles
caused
by
abusive handling in shipment are unavoidable. Cable plugs
and sockets may
be
loosened, switches (especially tilt switch-
es) may go out of adjustment. Plumb bob tilt switch
should
always be adjusted after game is set on loc·ation
anQ
leg
levelers are adjusted.
Visual inspections before
plugging in line cord:
1. Check
that
al~
cable
plugs are firmly seated in
proper
sockets.
2. Check that cables are clear of all moving parts
and relays.
3. Check for
any
wires
that
may have become disconnected.
4.
Check
switches
for loose solder or other
foreign
material that
may
have come
loose
in
shipment
and
could cause shorting of
contacts.
5. Check wires on relay
coils
fo~ proper
soldering
especially the bare (common) wire connecting a row
of
relay
coils. Cold solder
connections
may not
show up in.factory inspection, but vibration in
shipment
may
break contact.
6. Check that fuses are firmly seated and making good
contact •.
7. Check
(manually)
the stepping
andresetting
of all
step-up units.
The
wiper action should not be
sluggish.
8.
Check the
transformer for
any
foreign
material
shorting across wiring
lugs.
9. Check wiring of
transformer
to
correspond
to.loca-
tion voltage. (Transformer wiring
card in
front
cabinet) •
Before line
cord
is plugged
in:
Check all plugs and sockets and dress cables:
(A) Plugs
in correct
sockets.
-1-
