Score drums are easy to trouble shoot.
A
faulty unit can
be found visually. Visual inspection and adjustment is
adequate to correct the problem. Do not overlook cable
dress as a source of the problem. Dress bare leads away
from
adjacent
connections.
SECTION IV SERVICE PARTS
A
parts catalogue is available upon request. The catalogue is
illustrated and lists all replacement
parts
for each game manufac-
tured
by
Bally.
Requests
should be addressed to :
BALLY MANUFACTURING CORPORATION
2640
WEST BELMONT AVENUE
CHICAGO, ILLINOIS 60618
ATTENTION:
PARTS
DEPARTMENT
Enclose
$1.00
for postage
and
handling.
SERVICE HINTS
To
maintain trouble
free
operation, all stepping unit contact plates,
rivet and printed circuit type should be cleaned
and
lubricated
sparingly
every 30
days using Bally coin machine lubricant.
The Bally playfield has an improved tuff-coat finish with excellent
wearing properties. It's
life expectancy,
as
well
as
play appeal,
can be extended
by
periodic cleaning of the playfield.
DO:
Consult your local distributor for his product recommenda-
tions on this subject. Chances are, he has direct
experience
based
on usage. If not, clean with a mild
face
type
soap and a clean cloth dampened with water
or
clean
with a product manufactured specifically for
this purpose. Petroleum disillate based cleaners do
not harm
the
playfield finish. Polish, if desired •.
A
combination cleaner and polish such as Wildcat #125*
(Wildcat Chemical Co., 1333 W. Siminary Dr.,
Ft.
Worth,
Texas
76115)· or simply a cleaner such as Waterless
Lemonite Cleaner* (Graco Sales Co., Rebel Labs, 8152
Highway 70, Arlington, Tenn. 38002) cleans even the
dirtiest of
playfields
with
ease. Use all cleaning
agents sparingly. An
accumulation of re~idue can jam
roll-over buttons.
Inspect
and hand polish the ball in
a clean cloth. A chipped ball must be replaced. It
can
ruin the finish on the playfield in a short period
of
time.
DON'T: Use water in large quantities, highly caustic cleaners,
abrasive cleaners or cleaning pads on the playfield.
Do
not allow a wax or polish build up. Waxes yellow
with age and spoil play appeal.
Bally has tried these products and found them effective. Bally
assumes
no
responsibility
for
their use, however, as Bally has
nO
control over the manufacturers and any product changes they
may make.
