Leg
B*---++-- Leg Leveller
Shalt
lEAN7l.AJI J&JIlN
GAME ASSEMBLY INSTRUCTIONS
1. Open the shipping container; remove all cartons, parts, and 'other items, and set them aside.
Read the Warnings and Cautions labels and documents on
aru:LI.M
the game.
2.
Place the game cabinet on a support and open the coin door; unlatch and remove the Front
Molding Assembly to allow removing the lower playfield glass. This allows access for later game
adjustments, lubrication, etc.
3.
Attach the rear legs (after installing leg levellers), using leg bolts. Leg levellers and leg bolts are
both provided among the parts in the cash box. Attach the front legs (after installing leg
levellers), using leg bolts. See Figure
1
for details.
~~~
==!.J
Nut
~;;;;;;;;;~_
Leveller
Foot
Pad
_.-See DetailView
Detail View -
leg leveller
~~~t::-_~_'/O
degrees
- - -",l.ppl"Ox.
Pla';field
Pitch,l.ngle:
6 degrees
Figure 1. Pinball Assembly, Playfleld Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and check the mating of the interconnecting cables, match-
ing several wire colors at each connector. Ensure that all connections are properly secure.
©&'lUJii'IJ@1Nl
Ensure that the interconnecting cables are free to move (not kinked or pinched). Be
careful not to damage wires at any stage of the assembly process.
5. Take the two 2" black carriage bolts and, after swinging the hinged backbox upright, stabilize it in
position, while placing one carriage bolt up to its head through the locking hole on each side of
the lower apron sides of the backbox into the cabinet.
(WARNING)
NEVER
transport a pinball game with the hinged backbox erect.
Always
lower
the backbox forward onto the playfield cabinet on a layer of protective material
to prevent marring or damage and possible personal injury.
