MAINTENANCE INFORMATION
Figure 4 shows the two main lubrication points of the Ball Shooter Lane Feeder. The shaded arrows
show the directions in which the Ball Shooter Lane Feeder and other parts of its related assemblies
can be adjusted for proper operation. The Freestyle Kickbig on the upper playfield, as well as the Ball
Cannon Kickbig, the Lower Left and Right Kickers, and the Eject Hole Assembly (same for both the
Left and the Center Eject Holes) all utilize similar mechanisms. To provide your players with the best
game action, it is recommended that these devices be checked for operation regularly and lubricated
whenever a sluggish action is noted.
TOP VIEW
LUBE
POINTS
Figure 4. Adjustments and Lubrication Points, Ball Shooter Lane Feeder.
Lubrication to ensure proper operation also applies to other devices on
BANZAI RUN,
such as the
shaft of the Ball Popper and the Pop-up Flipper Post on the upper playfield. Regular maintenance is
essential to a game's continuing contribution to the operator's earnings.
