GAME ASSEMBLY INSTRUCTIONS
(Continued)
11. Adjust the leg levelers for proper playfield level (side-to-side)
.aJ1!1
playfield pitch angle (incline) of
approximately 6 to 6-1/2 degrees. (It is recommended that these measurements be made ON
the playfield, not the cabinet nor the playfield cover glass.) NOTE: 6-1/2 DEGREES IS THE
RECOMMENDED MAXIMUM ANGLE. THE LOWER PLAYFIELD'S LEFT BALL GUIDE AT THE
EXIT OF THE RAMP MAY REQUIRE ADJUSTMENT TO RETURN THE BALL TO THE MIDDLE
OF THE RIGHT FLIPPER PADDLE IF A GREATER ANGLE IS USED. Tighten the nut on each
leg leveler shaft to maintain this setting, as shown in Figure 1.
~&.lUJIl1l©lNl
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside
the cabinet. The operator should adjust this tilt mechanism for proper operation, after
completion of the desired playfield pitch angle setting.
12. Move the game into the desired location; recheck the level and pitch angle of the playfield. To
verify that the game's playfield is properly aligned for good play, remove the lower playfield glass
and place a ball just left of center of the plastic runway.
NOTE
For good play, the ball should roll from a standing start down the runway exit,
along the curved left ball guide to the center of the right flipper paddle. Adjust
the curved left ball guide to provide this ball pathway.
Also, check that the
alignment of the 'Ball Cannon' (Kickbig near the lower left return lane) causes a
ball shot to strike the captured ball on the lower playfield; adjust via the nuts
atop the Ball Cannon plastic cover.
13. Place the
required number
of balls in the game.
(BANZAI
RUN:
3 balls into outhole of lower
playfield. Also, verify that 1 smaller ball was installed in the Freestyle area of the upper playfield
(step 7). Verify that one ball is retained in the captured ball runway (upper center) of the upper
playfield (step 7) and that one ball is retained in the leftside captured ball runway of lower playfield
(step 9), after removal of their sleeve holders.)
14. Clean and re-install the playfield cover glasses. Ensure that the black plastic Lower Playfield
Glass Molding Strip is located on the top edge of the lower playfield glass. Slide the Lower
Playfield Glass upward in its mounting grooves, until it is firmly against the Barrier Molding
Assembly, as shown in Figure 2, right view. Re-install the Front Molding Assembly to complete
the game assembly and setup procedure. Prepare the game for your players: Plug it in, turn it
on, and check for proper operation.
GAME OPERATION
( WARNING)
After assembly and installation at its site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DO NOT
use a 'cheater' plug to defeat the ground pin on the line cord. DO NOT cut off the ground pin.
POWERING UP. With the coin door closed, plug the game in, and swltch it .oN, using the On-Off
switch. In normal operation, the Player 1 score display initially shows 00. Then, the game goes into
the Attract Mode (playfield and backbox lamps flashing, sounds being heard, etc., if the operator does
not change the Factory Setting).
Open the coindoor and press the AUTO-UP/MANUAL-DOWN switch to MANUAL-DOWN.
Press the
ADVANCE button to begin the game test routine. Then, return to AUTO-UP and perform the entire
test to verify that the game is operating satisfactorily.
