Item Part No.
Description
Playfield
Parts
1 03·7542·9 Post
a) 23·6300
RUbber
2 12·6842
Bottom Arch Fence
3 C·11626-L-3 Lwr Left Flipper Assy
a} 20-9250-6 Lg Flipper Paddle & Shaft
4 8·12363-L Left Flipper Return Frame
5 8-12665
Kicker Arm ("Sling") Assy
a) 8·11203· R-1 Coil & Bracket Assy
6 12·6865
Wire Ramp
7 C·13116
5-Bank Drop Target Assy
8 A·13109
Left Ramp Ball Gate (Entry)
a) 12-6874
GateWire
b) 12-6853-1 Switch Actuating Wire
9 R-12974
Left Ramp Assembly
10 A-12846
Cntr Ramp Ball Gate (Entry)
a) 12·6847
GateWire
b) 12·6873-1 Switch Actuating Wire
11 D-12975
Center Ramp Assembly
12 B-9361-R·5 Top Left Eject Hole
a} B-9362-R-1 Coil
&
Bracket Assembly
b) 03-7351-1-9 Tr Red Plastic Ball Seat
13 A-9465-L
Ball Gate Assembly
a) 12·6565
Gate Wire
14 A-13161
8allGuideAssy
158-13110
8allGuideAssy
16 A-13019
Ball Guide Assembly
17 8-13016
Linear Target Arm Assy
18 A-13019
Ball Guide Assembly
19 C-13021
Ball Guide Assembly
20 12-6868
Wireform
21 A·12511
i-Way Ball Gate
22 12-6466-3 Wireform,
3/4"
(2
ea,
4 sites)
23 A·12511
i-Way Ball Gate
24 6·13123
Jet 8umper Assy
a) 8-9415-1
Bmpr CoiVBracketAssy
25 8-9414
Jet Bumper Assy (2)
a) B-9415·1
Bmpr Coil/Bracket Assy
26 C-11223-1 3-Bank Drop Target Assy
27 C-11987·1 Doghouse Kickbig Assembly
28 A·13249
Ball Guide Assy
29 8-13248
Ball Guide Assy
30 C-12036-2 Seafood Wheel Assembly
31 12-6466-5 Wireform,
1·114"
32 8-12363-R Right Flipper Return Frame
33 C-11626-R-3 Lwr Right Flipper Assy
a} 20-9250-6 Flipper Arm on Shaft
34 Parts below are located beneath Bottom Arch:
a) 01-3569
Ball Trough (runway)
b) 01-3570-3 Upper Ball Trough Guide
c} 01-3571-3 Lower Ball Trough Guide
d) 12-6557
Baffle Wire
e) B-8039·2
Outhole Kicker
