AS-2518-132 RECTIFIER BOARD ASSEMBLY
J
(Part of) A2:
POWER TRANSFORMER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
*
DESCRIPTION
0
A2
AS-2877-11
Power Transformer Module.
Complete
PIOAS
AS-2518-132
Rectifier Board Assembly,
Complete
3
Rl
E-00104-092
Resistor, 10%.600 Ohm, lOW
4
R2
E-00104-0091
Resistor, 25 Ohm, 5W
5
R3
E-00105-0226
Resistor, 5%, lOOK Ohm, y.,W
7
VRl
E-00623
Varistor
8
CR5, CR6, CR7, CR8
E-00587-32
6A Diode
9
CR1, CR2, CR3, CR4
E-00587-0015
Diode (IN4004)
10
11
Used with BRl-2
P-1973-480
Spacer
12
BR1, BR2
E-00602-0007
Bridge Rectifier
15
F2
E-00133-0028
Fuse, %A, 250V, 3AG
16
F3
E-00133-0006
Fuse, 6A, 32V, 3AG
17
F4
E-00133-0005
Fuse, 5A, 32V. 3AG
18
F1
E-00 133-0027
Fuse, 20A. 32V, 3AG
19
F5,F6
E-00133-0015
Fuse, 15A, 32V, 3AG
20
Jl
E-806-9
9 CKT Socket Header
21
TP1, 2.3,4,5
P-05399
Test Clip
22
J2, J6
E-805-6
6 CKT Pin Header
23
J4, J5
E-805-9
9 CKT Pin Header
24
J3
E-805-12
12 CKT Pin Header
25
F2,3,4
E-00148-0021
Fuse Clips
26
Fl,5,6
E-00148-0022
Fuse Clips (Low Resistance)
